Ronstan Sailboat Hardware | SKU:
RONRA6402
Ronstan 40QT Orbit Winch with QuickTrim
Regular price
$1,089.00
Unit price
Pickup available at 1830 East Interstate 30
Usually ready in 24 hours
Shipping and Delivery
Free shipping for orders of $98 or more (US Continental)
- Free shipping for orders of $750 or more (International)
- Add 3 business days to the standard shipping time for USPS deliveries.
- UPS and FedEx Ground usually take 2 to 5 business days for in-stock orders.
- UPS and FedEx deliver on Saturdays only for Friday overnight shipments, which may incur an extra
charge. - Orders that apply for free shipping will be delivered between 8 and 10 business days.
- International customers will be responsible for any applicable import duties,fees, or taxes.
- Oversized items like whisker poles, spinnaker poles, and tracks over 7 feet require freight shipping, with an estimated cost of $500 depending on the destination.These orders must be delivered to a
commercial address, such as a marina, yacht club, or boatyard where your sailboat is located.
A recipient must be present to sign for the delivery upon arrival,For more info, Click Here.
Ronstan 40QT Orbit Winch with QuickTrim
Regular price
$1,089.00
Unit price
Ronstan 40QT Orbit Winch with QuickTrim
Features:
- Sprung self-tailing jaws to accept 7 - 12mm line.
- QuickTrim patented self-tailing feature for rapid sail trim and smooth adjustment.
- Ball bearings carry the thrust loads, roller bearings carry the radial loads of the drum to minimise rotational friction.
- Proven Andersen winch gearing configuration.
- Power Rib ensures a controlled grip on the line at all times, whether trimming or easing. Minimal rope wear compared to more abrasive drum surface finishes.
- No tools required for configuration and servicing.
- Machined aluminium drum – stronger and lighter than traditional cast aluminium drums.
- Aluminium centre stem, lighter weight compared to bronze stems.
- Low line entry due to gearing configuration geometry.
Specifications:
- Gear ratio 1st speed: 1.4:1
- Gear ratio 2nd speed: 6.8:1
- Power ratio 1st speed: 8.3:1
- Power ratio 2nd speed: 40:01:00
