Ronstan Sailboat Hardware | SKU:
RONRC1190-1.5S
Ronstan Series 19 Track. Silver. 1496 mm M5 CSK fastener holes. Pitch=100mm. Stop hole pitch=50mm
Regular price
$136.00
Unit price
Pickup available at 1830 East Interstate 30
Usually ready in 24 hours
Shipping and Delivery
Free shipping for orders of $98 or more (US Continental)
- Free shipping for orders of $750 or more (International)
- Add 3 business days to the standard shipping time for USPS deliveries.
- UPS and FedEx Ground usually take 2 to 5 business days for in-stock orders.
- UPS and FedEx deliver on Saturdays only for Friday overnight shipments, which may incur an extra
charge. - Orders that apply for free shipping will be delivered between 8 and 10 business days.
- International customers will be responsible for any applicable import duties,fees, or taxes.
- Oversized items like whisker poles, spinnaker poles, and tracks over 7 feet require freight shipping, with an estimated cost of $500 depending on the destination.These orders must be delivered to a
commercial address, such as a marina, yacht club, or boatyard where your sailboat is located.
A recipient must be present to sign for the delivery upon arrival,For more info, Click Here.
Ronstan Series 19 Track. Silver. 1496 mm M5 CSK fastener holes. Pit...
Regular price
$136.00
Unit price
Manufacturer part #: RC1190-1.5S
Technical Description
Series 19 Silver Track
3/4 in
19.4 mm
13/32 in
10.4 mm
59 in
1496 mm
16.4 oz
465 g
Manufacturer part #: RC1190-1.5S
Track is supplied with RC7250-INS insulating inserts to eliminate corrosion between track and fasteners.
Track Fastenings
To suit 5 mm (3/16") countersunk head fasteners at 100 mm (3 15/16") centres.
Stop Holes
50 mm (2") Centres.
Minimum Curve Radius
For 50 mm (1 31/32") car
Min horizontal 'A' curve radius = 1500 mm (59"). Min horizontal 'B' curve radius & 1500 mm (59").
For 57 mm (2 1/4") car
Min horizontal 'A' curve radius = 1500 mm (59"). Min horizontal 'B' curve radius = 1500 mm (59").
For 70 mm (2 3/4") car
Min horizontal 'A' curve radius = 2500 mm (99"). Min horizontal 'B' curve radius = 3000 mm (118").
For 85 mm (3 11/32") car
Min horizontal 'A' curve radius = 3500 mm (138"). Min horizontal 'B' curve radius = 4500 mm (177").
For 100 mm (3 15/16") car
Min horizontal 'A' curve radius = 5000 mm (197"). Min horizontal 'B' curve radius = 5500 mm (217").
For 148 mm (5 27/32") car
Min horizontal 'A' curve radius = 11000 mm (433"). Min horizontal 'B' curve radius = 15000 mm (591 ).
Standard low profile track has stop holes to accept cars with plunger stops.
Applications
Dinghy and catamaran mainsheet traveller and jib lead sheeting systems
Mainsheet systems on sportsboats and keel boats to 7 m (23 ft)
