Ronstan Sailboat Hardware | SKU:
RONRC1190-2.0S
Ronstan Series 19 Track. Silver. 1996 mm M5 CSK fastener holes. Pitch=100mm Stop hole pitch=50mm
Regular price
$170.20
Unit price
Pickup available at 1830 East Interstate 30
Usually ready in 24 hours
Shipping and Delivery
Free shipping for orders of $98 or more (US Continental)
- Free shipping for orders of $750 or more (International)
- Add 3 business days to the standard shipping time for USPS deliveries.
- UPS and FedEx Ground usually take 2 to 5 business days for in-stock orders.
- UPS and FedEx deliver on Saturdays only for Friday overnight shipments, which may incur an extra
charge. - Orders that apply for free shipping will be delivered between 8 and 10 business days.
- International customers will be responsible for any applicable import duties,fees, or taxes.
- Oversized items like whisker poles, spinnaker poles, and tracks over 7 feet require freight shipping, with an estimated cost of $500 depending on the destination.These orders must be delivered to a
commercial address, such as a marina, yacht club, or boatyard where your sailboat is located.
A recipient must be present to sign for the delivery upon arrival,For more info, Click Here.
Ronstan Series 19 Track. Silver. 1996 mm M5 CSK fastener holes. Pit...
Regular price
$170.20
Unit price
Manufacturer part #: RC1190-2.0S
Technical Description
Series 19 Silver Track
3/4 in
19.4 mm
13/32 in
10.4 mm
78 5/8 in
1996 mm
6.1 oz
21.9 g
Manufacturer part #: RC1190-2.0S
Track is supplied with RC7250-INS insulating inserts to eliminate corrosion between track and fasteners.
Track Fastenings
To suit 5 mm (3/16") countersunk head fasteners at 100 mm (3 15/16") centres.
Stop Holes
50 mm (2") Centres.
Minimum Curve Radius
For 50 mm (1 31/32") car
Min horizontal 'A' curve radius = 1500 mm (59"). Min horizontal 'B' curve radius & 1500 mm (59").
For 57 mm (2 1/4") car
Min horizontal 'A' curve radius = 1500 mm (59"). Min horizontal 'B' curve radius = 1500 mm (59").
For 70 mm (2 3/4") car
Min horizontal 'A' curve radius = 2500 mm (99"). Min horizontal 'B' curve radius = 3000 mm (118").
For 85 mm (3 11/32") car
Min horizontal 'A' curve radius = 3500 mm (138"). Min horizontal 'B' curve radius = 4500 mm (177").
For 100 mm (3 15/16") car
Min horizontal 'A' curve radius = 5000 mm (197"). Min horizontal 'B' curve radius = 5500 mm (217").
For 148 mm (5 27/32") car
Min horizontal 'A' curve radius = 11000 mm (433"). Min horizontal 'B' curve radius = 15000 mm (591 ).
Standard low profile track has stop holes to accept cars with plunger stops.
Applications
Track is supplied with RC7250-INS insulating inserts to eliminate corrosion between track and fasteners.
Track Fastenings
To suit 5 mm (3/16") countersunk head fasteners at 100 mm (3 15/16") centres.
Stop Holes
50 mm (2") Centres.
Minimum Curve Radius
For 50 mm (1 31/32") car
Min horizontal 'A' curve radius = 1500 mm (59"). Min horizontal 'B' curve radius & 1500 mm (59").
For 57 mm (2 1/4") car
Min horizontal 'A' curve radius = 1500 mm (59"). Min horizontal 'B' curve radius = 1500 mm (59").
For 70 mm (2 3/4") car
Min horizontal 'A' curve radius = 2500 mm (99"). Min horizontal 'B' curve radius = 3000 mm (118").
For 85 mm (3 11/32") car
Min horizontal 'A' curve radius = 3500 mm (138"). Min horizontal 'B' curve radius = 4500 mm (177").
For 100 mm (3 15/16") car
Min horizontal 'A' curve radius = 5000 mm (197"). Min horizontal 'B' curve radius = 5500 mm (217").
For 148 mm (5 27/32") car
Min horizontal 'A' curve radius = 11000 mm (433"). Min horizontal 'B' curve radius = 15000 mm (591 ).
Standard low profile track has stop holes to accept cars with plunger stops.
Applications
- Dinghy and catamaran mainsheet traveller and jib lead sheeting systems
- Mainsheet systems on sportsboats and keel boats to 7 m (23 ft)
- Alloy
