UBI FR125 ReWind Furler System Free Tack Top Down With Lock
FR125RWm ReWind Furler System With Lock
FR RE2wIND®, a bow sail furler, is a brilliant solution for the management of both code zero and gennaker sails.
In fact, it is the first-ever furler with a PATENTED ratchet system, which can be excluded. This product is advantageous firstly because it facilitates sail winding: the internal ratchet (which is easy to fit by textile activation), stops the sail unfolding during winding. Thus, the loop can be disengaged while the sail is closing, without the risk of the sail unfolding involuntarily.
This increases the sailor’s safety, as in rough seas or strong winds, he/she can let go of the loop to keep his/her balance or deal with any unexpected problems.
These features are all combined in a compact and lightweight product. Indeed, RE2wIND® differs from normal FR furlers thanks to its original lay-out and its ratchet selector system in the carter bottom. RE2wIND® comes in two versions: Rw with fixed tack (code zero, genoa, etc) Rwm with free tack to wind gennakers whitout luff.
Drum And Head ALUMINIUM alloy 6082T6, machined from a single piece and anodized
Drum Guard NYLON 3d printed Bearings Cylindrical roller thrust bearings
X-Bearing system by UBI MAI1R ITALIA® on free tack up to FR150Rwm model
Other AISI 316 and 17-4Ph STEEL hub and screws Hub adjustment and locking by socket set in 12 positions
FR ReWind Free Tack Furlers
| Model | Roller Drum ø | Pin ø | Max Line ø | Max Working Load | Breaking Load | Head + Stay Hook Weight | Drum + Stay Hook Weight | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | in | mm | in | mm | in | kg | lb | kg | lb | g | oz | g | oz | |
| FR100RWm | 100 | 4 | 8 | 1/64 | 8 | 1/64 | 1500 | 3307 | 3000 | 6614 | 220 | 8 | 860 | 30 |
| FR125RWm | 125 | 4 15/16 | 10 | 3/8 | 8 | 5/16 | 3000 | 6614 | 6000 | 13228 | 350 | 12 | 1330 | 47 |
| FR150RWm | 150 | 5 29/32 | 12 | 1/2 | 10 | 3/8 | 5000 | 11023 | 10000 | 22046 | 400 | 14 | 1500 | 53 |
| FR200RWm | 200 | 7 7/8 | 14 | 9/16 | 10 | 3/8 | 7,500 | 16535 | 15000 | 33069 | 750 | 26.5 | 2300 | 81 |
| FR250RWm | 250 | 9 27/32 | 16 | 5/8 | 10 | 3/8 | 10000 | 22046 | 20000 | 44092 | 900 | 31.75 | 3550 | 125 |
| FR250RWHm | 250 | 9 27/32 | 16 | 5/8 | 10 | 3/8 | 13000 | 28660 | 26000 | 57320 | 975 | 34 | 3670 | 129 |
